Engine & Performance

Type	SI, 4 stroke, 4 valve, Single cylinder, Liquid cooled, Reverse inclined
Engine capacity	312.2cc
Maximum power	Sport and Track mode – 28 kW@9800 engine rpm (38 PS@9800 engine rpm)
	Urban and rain mode – 22 kW@7600 engine rpm (30 PS@7600 engine rpm)
Maximum torque	Sport and Track mode – 29 Nm@7900 engine rpm
	Urban and rain mode – 26.5 Nm@6700 engine rpm
Bore	80 mm
Stroke	62.1 mm
Fuel injection	Bosch – Closed loop RT-FI
Throttle control	Electronic throttle control with multiple ride modes
Bore to stroke ratio	1.29
Starting	Electric start
Idle speed	1700 ± 200rpm
Ignition	Dynamically controlled integrated high energy ignition system
Power to weight Ratio	0.144 kW/kg
Compression ratio	12.17 :1
Air filter	Dry Paper filter
Cooling system	Liquid cooled
Muffler	Single pipe and single body design
Clutch	Wet multi plate – 7 plate design, RT slipper clutch
Gear box	6 speed
Max speed	164 km/h – Sport and Track mode
0-60km/h (time in sec)	2.82 s
0-100km/h (time in sec)	6.74 s

image credit:- Tvs Motor Company

Chassis, Suspension & Electrical

Frame	Trellis frame, split chassis
Front Suspension	Inverted cartridge telescopic Fork
Rear Suspension	Two arm Aluminium die-cast swingarm
	Mono tube floating piston gas assisted shock absorber
Battery	12V, 8Ah
Headlamp	Bi-LED projector, 30W@13 V
Tail Lamp	LED 4 W
Instrument cluster	5″ TFT screen connected cluster

Image Credit:- Tvs Motor Company

Rim Size (Front)	MT 3.0×17
Rim Size (Rear)	MT 4.0×17
Tyre Size (Front)	110/70-ZR17 M/C 54W Tubeless – Michelin ROAD5
Tyre Size (Rear)	150/60-ZR17 M/C 66W Tubeless – Michelin ROAD5
Front	Disc 300mm Petal type with ABS
Rear	Disc 240mm Petal type with ABS
ABS	With 3 ride modes
Brake Fluid	DOT 4

Image Credit:- Tvs Motor Company

Image Credit:- Tvs Motor Company
